Huba Control 692 Differential Pressure Transmitter

Huba Control Differential Pressure Transmitter 692.916007141

Huba Control Differential Pressure Transmitter 692.916007141


  • Brand : Huba Control
  • Model : 692.916007141
  • Range : 0-2.5 Bar
  • Type : 692 0-2.5 Bar
  • Current Out : 4-20mA
  • Voltage : 24 ( 11-33V DC )
  • MAX : P1-P2 12BAR
  • MAX : P2-P1 12BAR
  • Made In Switzerland

Huba Control Differential Pressure Transmitter

Product Information

Differential Pressure Transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.916007141
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechindia.net
  • www.envirotechdelhi.info
  • www.envirotechindia.info

Huba Control Differential Pressure Transmitter 692.916007141


Huba Control Differential Pressure Transmitter 692

Huba Control Differential Pressure Transmitter 692

Product Information

Differential pressure transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechdelhi.co.in
  • www.envirotechdelhi.net
  • www.envirotechdelhi.in

Huba Control Differential Pressure Transmitter 692


Huba Control Differential Pressure Transmitter 692.915007141

Huba Control Differential Pressure Transmitter 692.915007141

  • Brand : Huba Control
  • Model : 692.915007141
  • Range :  0...+2.5 BAR
  • Type : 692 0...+2.5 BAR
  • Current Out : 4-20mA
  • Voltage : 11-33V DC
  • MAX : P1-P2 5BAR
  • MAX : P2-P1 5BAR
  • Made In Switzerland

Huba Control Differential Pressure Transmitter

Product Information

Differential Pressure Transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.915007141
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechindustrialproducts.co.in
  • www.envirotechindustrialproduct.in
  • www.envirotechindustrialproduct.co.in

Huba Control Differential Pressure Transmitter 692.915007141


Huba Control Differential Pressure Transmitter 692.918001161

Huba Control Differential Pressure Transmitter 692.918001161

  • Brand : Huba Control
  • Model : 692.918001161
  • Range : 0-4 Bar
  • Type : 692 0-4 Bar
  • Current Out : 0-10 VDC  / 24 VAC ±15 %
  • IN - 18-33 VDC
  • Made In Switzerland

Huba Control Differential Pressure Transmitter 692

Product Information

Differential pressure transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.918001161
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechdelhi.in
  • www.envirotechdelhi.net
  • www.envirotechindia.co.in

Huba Control Differential Pressure Transmitter 692.918001161


Huba Control Differential Pressure Transmitter 692.916101141

Huba Control Differential Pressure Transmitter 692.916101141

  • Brand : Huba Control
  • Model : 692.916101141
  • Range : 0-2.5 Bar
  • Type : 692 0-2.5 Bar
  • Current Out : 0-10 VDC  / 24 VAC ±15 %
  • IN - 18-33 VDC
  • Made In Switzerland

Huba Control Differential Pressure Transmitter 692

Product Information

Differential pressure transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.916101141
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechindustrialproduct.com
  • www.envirotechindustrialproducts.in
  • www.envirotechindustrialproduct.in

Huba Control Differential Pressure Transmitter 692.916101141



Huba Control Differential Pressure Transmitter 692.918007101

 Huba Control Differential Pressure Transmitter 692.918007101


  • Brand : Huba Control
  • Model : 692.918007101
  • Range : 0-4 Bar
  • Type : 692 0-4 Bar
  • Current Out : 4-20mA
  • Voltage : 24 ( 11-33V DC )
  • MAX : P1-P2 12BAR
  • MAX : P2-P1 12BAR
  • Made In Switzerland

Huba Control Differential Pressure Transmitter

Product Information

Differential Pressure Transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.918007101
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechindustrialproductsdelhi.com
  • www.envirotechindustrialproduct.info
  • www.envirotechindustrialproductsindia.in

Huba Control Differential Pressure Transmitter 692.918007101

Huba Control Differential Pressure Transmitter 692.919007161

 Huba Control Differential Pressure Transmitter 692.919007161


  • Brand : Huba Control
  • Model : 692.919007161
  • Range :  0...+6 BAR
  • Type : 692 0...+6 BAR
  • Current Out : 4-20mA
  • Voltage : 11-33V DC
  • MAX : P1-P2 12BAR
  • MAX : P2-P1 12BAR
  • Made In Switzerland

Huba Control Differential Pressure Transmitter

Product Information

Differential Pressure Transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.919007161
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechindustrialproducts.info
  • www.envirotechdelhi.com
  • www.envirotechindia.co.in

Huba Control Differential Pressure Transmitter 692.919007161

Huba Control Differential Pressure Transmitter 692.911017011

 Huba Control Differential Pressure Transmitter 692.911017011


  • Brand : Huba Control
  • Model : 692.911017011
  • Range :  0...+1 BAR
  • Type : 692 0...+1 BAR
  • Current Out : 4-20mA
  • Voltage : 11-33V DC
  • MAX : P1-P2 2BAR
  • MAX : P2-P1 2BAR
  • Made In Switzerland

Huba Control Differential Pressure Transmitter

Product Information

Differential Pressure Transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.911017011
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechdelhi.in
  • www.envirotechdelhi.net
  • www.envirotechindia.info

Huba Control Differential Pressure Transmitter 692.911017011

Huba Control Differential Pressure Transmitter 692.919007141

 Huba Control Differential Pressure Transmitter 692.919007141


  • Brand : Huba Control
  • Model : 692.919007141
  • Range : 0-6 Bar
  • Type : 692 0-6 Bar
  • Current Out : 4-20mA
  • Voltage - 11-33V DC
  • Made In Switzerland

Huba Control Differential Pressure Transmitter 692

Product Information

Differential pressure transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.919007141
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechdelhi.com
  • www.envirotechdelhi.in
  • www.envirotechindia.co.in

Huba Control Differential Pressure Transmitter 692.919007141

Huba Control Differential Pressure Transmitter Model 692.914007141 Range : 0...+1.6 BAR

 Huba Control Differential Pressure Transmitter Model 692.914007141 Range :  0...+1.6 BAR


  • Brand : Huba Control
  • Model : 692.914007141
  • Range :  0...+1.6 BAR
  • Type : 692 0...+1.6 BAR
  • Current Out : 4-20mA
  • Voltage : 11-33V DC
  • MAX : P1-P2 12BAR
  • MAX : P2-P1 12BAR
  • Made In Switzerland

Huba Control Differential Pressure Transmitter

Product Information

Differential Pressure Transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate


Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter Model 692.914007141 Range :  0...+1.6 BAR
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechdelhi.com
  • www.envirotechindia.co.in
  • www.envirotechindustrialproducts.info

Huba Control Differential Pressure Transmitter Model 692.914007141 Range :  0...+1.6 BAR

Huba Control Differential Pressure Transmitter 692.918007141

 Huba Control Differential Pressure Transmitter 692.918007141


  • Brand : Huba Control
  • Model : 692.918007141
  • Range :  0...+ 4 BAR
  • Type : 692 0...+4 BAR
  • Current Out : 4-20mA
  • Voltage : 11-33V DC
  • MAX : P1-P2 12BAR
  • MAX : P2-P1 12BAR
  • Made In Switzerland

Huba Control Differential Pressure Transmitter 692

Product Information

Differential pressure transmitter 692

The Pressure Transmitters of Type 692 Feature The Unique And Proven Ceramic Technology. Depending On The Application, Various Pressure Connections And Electrical Connections With Standardized Output Signals Are Available. Due To The Wide Variety Of Options, The Transmitters 692 Are Suitable For All Types Of Industrial Applications.

  • Very Low Temperature Sensitivity
  • High Temperature Resistance
  • No Mechanical Creep
  • Individual Applications Through Modular System And Different Material Choices

Technical Data

Product Feature

  • Pressure Measuring Range : 0 ... 25 Bar (Relative And Difference)
  • Response Time : <5 ms
  • Load Change : <50 Hz
  • Sensor Weight : 430 g

Field Of Application

  • Media : Process Medium; Gas
  • Medium Temperature : -15 ... 85 °C
  • Permissible Overload On One Side : See Variant Plan
  • System Pressure : 12; 25; 50 Bar
  • Bursting Pressure : 1.5 x System Pressure

Ambient Condition

  • Ambient Temperature : -15 ... 85 °C
  • Storage Temperature : -40 ... 85 °C

Material

  • Housing : Stainless Steel 1.4305 (AISI 303); PVDF
  • Pressure Connection With Media Contact : Stainless Steel 1.4305 (AISI 303); PVDF; CuZn Vni
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)
  • Sealing Material With Media Contact : FPM; EDPM; NBR; MVQ; CR

Electrical Data

  • Current Consumption : <20 mA
  • Inverse-Polarity Protection : Short-Circuit And Reverse Polarity Protected. Each Connection Against Each Other With Max. Supply Voltage.

Installation Guide

  • Installation Orientation : any
  • Assembly : Mounting Bracket

Approval


EMC Compatibility : CE-Compliant In Accordance With EN 61326-2-3

Applications

  • REFRIGERATION SYSTEMS
  • CPU
  • WATER PUMPS
  • ULTRAFILTRATION SYSTEM

Accessories


  • Mounting Bracket
  • Socket Outlet DIN EN 175301-803-A : With Seal; IP 65, When Mounted And Screwed.
  • Socket Outlet DIN EN 60130-9 : IP 65, When Mounted And Screwed.
  • Calibration Certificate




Additional Information:

  • Item Code: Huba Control Differential Pressure Transmitter 692.918007141
  • WhatsApp No.9871034100,9868958924,9650264867,9716640145,8368866030,8368801023
  • www.envirotechdelhi.co.in
  • www.envirotechdelhi.info
  • www.envirotechindia.net

Huba Control Differential Pressure Transmitter 692.918007141
